Heightmap issues

[jean_milost]

I’m trying to create a mountain system from a heightmap, based on this example: https://www.youtube.com/watch?v=fEG_cnRQ1HI

The idea is simple:

1. Create a MeshInstance3D with a PlaneMesh of WidthDepth vertices (8080 in my case), create a Shader for the mesh, read the heightmap image from it, and for each level of grey, modify the vertex Y coordinates
2. In the MeshInstance3D (as a child of it), create a StaticBody3D with a child CollisionShape3D, add a script to the parent MeshInstance3D, which will build a collision shape, based on the same heightmap image as used in the Shader

But in my project, this not works as expected. I have indeed a more or less matching collision shape, but it contains several important differences, which turn it unusable because not reliable (see screenshot below).

Below is the code of my script:

extends MeshInstance3D

@onready var colShape = $StaticBody3D/CollisionShape3D

@export var chunk_size = 2.0
@export var height_ratio = 0.5
@export var colShape_size_ratio = 0.5#0.1

var img = Image.new()
var shape = HeightMapShape3D.new()

# Called when the node enters the scene tree for the first time.
func _ready():
	colShape.shape = shape
	mesh.size = Vector2(chunk_size, chunk_size)
	update_terrain(height_ratio, colShape_size_ratio)

func update_terrain(_height_ratio, _colShape_size_ratio):
	mesh.material.set("shader_parameters/height", _height_ratio)

	img.load("res://assets/models/mountains/heightmap.png")
	img.convert(Image.FORMAT_RF)
	img.resize(img.get_width() * _colShape_size_ratio, img.get_height() * _colShape_size_ratio)

	var data = img.get_data().to_float32_array()

	for i in range(0, data.size()):
		data[i] *= _height_ratio

	shape.map_width = img.get_width()
	shape.map_depth = img.get_height()
	shape.map_data  = data

	var scale_ratio = chunk_size / float(img.get_width())
	colShape.scale  = Vector3(scale_ratio, 1, scale_ratio)

And here is the heightmap image I’m using:

I suspect that the ghost artifacts in my collision shape may come from a conversion issue, something like the collision shape is created 3 times due to the RGB values, but I cannot find how and where. I tried to convert the image to grayscale, or use a .exr format as suggested in the above video, but no way.

Can someone explain me what I’m doing wrong?

[smix8]

Note that PNG images are low quality for heightmaps in Godot. For the full 32 bit height data (FORMAT_RF) you need to use an e.g. EXR file format, not PNG.

That tutorial is old. There is a dedicated function by now on the HeightMapShape3D to create the height points from a grayscale image in all 3 common 1 channel image formats.

See HeightMapShape3D — Godot Engine (stable) documentation in English for the update_map_data_from_image(), also with a script example in the HeightMapShape3D class description at the begin of the page.

[jean_milost]

@smix8 Thank you for the explanations. However your solution is correct only since Godot 4.3 and higher. But as I’m still using Godot 4.2, the update_map_data_from_image() function does not exist on this version.

Anyway I could find what was my issue: I wrongly used the same script in 2 meshes on 2 different scenes, and contrary to what I thought, turning a scene hidden on the editor does not deactivate its collider, only the mesh visibility. For that reason, I had 2 superposed colliders, which were generated in different configuration, it was the reason why I had such ghosts when I ran my project.

But once again, thank you very much for the time you took to answer my question.
