Godot Version
4.6.3
Question
Hey New to Godot and have been following this tutorial on Youtube:
I got to the point of trying to test the code, but it is coming back with a error saying this " get_data_vaule: Invalid access to property or key ‘4’ on a base object of type ‘Dictionary’." I looked at the code on the Main Data Manager -Line 21- and the code seems fine, but I noticed it seems to through up errors dealing with the selection. And Key 4 seems to be The “OBJ_SELECTED,” in the Data Const. Been trying to figure it out but is very confusing. Here is my full error:
E 0:00:00:796 get_data_vaule: Invalid access to property or key ‘4’ on a base object of type ‘Dictionary’.main_data_manager.gd:21 @ get_data_vaule() main_data_manager.gd:21 @ get_data_vaule()
action_selectable.gd:38 @ _set_obj_selected_to()
action_selectable.gd:30 @ deselect_obj()
action_selectable.gd:27 @ initialize_action()
main_actions_manager.gd:24 @ initialize_actions()
base_unit.gd:42 @ _startup()
base_unit.gd:27 @ _ready()"
Here are the Code in the Files:
Main Data Manager:
#meta-space-indent: 4
extends RefCounted
## enums
## consts
const SCRIPT_OBJDATA_CONTS: = preload("res://Data/World/Objects/Comps/Data/data_consts.gd")
## exports
## public vars
## private vars
## onready vars
# Obj_ for Node Refs
## built-in override methods
## public methods
static func debug_data_dict(obj_caller:Node) -> void:
print("\n>>DEBUG_PRINT: 'obj_data' from Node'",obj_caller.name,"'")
var obj_data:Dictionary = get_data_dict(obj_caller)
for data in obj_data.keys():
#
print(SCRIPT_OBJDATA_CONTS.DATA_ENUMS.keys()[data], " : ", obj_data[data]," TYPE> ",
Globals.get_vartype_string_from_var(obj_data[data]))
static func get_data_dict(from_object:Node) -> Dictionary:return from_object.obj_data
static func get_data_value(from_object:Node,key:int) -> Variant:return from_object.obj_data[key]
static func has_data_key(from_object:Node,key:int) -> bool:return (from_object.obj_data as Dictionary).has(key)
static func set_data_vaule(from_object:Node,data_key:int,new_data_value:Variant) -> void:
# Ensure type safety before changing it.
if has_data_key(from_object,data_key):#(from_object.obj_data as Dictionary).has(data_key)
var current_var:Variant = from_object.obj_data[data_key]
if typeof(current_var) != typeof(new_data_value):
push_error(
"\n>>Type mismatch:For set_data_vaule()! For object: ", from_object.name,
"\n>>Expected'",Globals.get_vartype_string_from_var(current_var),"'but got'",
Globals.get_vartype_string_from_var(new_data_value),"'.'",
"\n<--->Key Enum Int: ",data_key,
"\n<--->Old_Var:",from_object.obj_data[data_key],
"\n<--->New_Var:",new_data_value,
)
return # Unexpected change in type
# Set Data for Object
static func add_data_vaule(from_object:Node, data_key:int, new_data_vaule:Variant) -> void:
#Adds vaule to a data as Array. check for dupicate.
if has_data_key(from_object,data_key): #if (from_object.obj_data as Dictionary).has(data_key)
var expected_array: Variant = get_data_value(from_object,data_key)
if expected_array is Array:
if (expected_array as Array).find(new_data_vaule):return #Data Already present.
else: (from_object.obj_data[data_key] as Array).append(new_data_vaule) # Apppends new vaule
set_data_vaule(from_object,data_key,new_data_vaule) #What if we want an array instead?
## private methods
Main Action Manager:
#meta-space-indent: 4
extends RefCounted
# Manages and stores actions
## enums
## consts
const SCRIPT_ACTS_CONST: = preload("res://Data/World/Objects/Comps/Actions/actions_conts.gd")
const ACTION_SCRIPT:Dictionary[int,Script] = {
SCRIPT_ACTS_CONST.ACTION_NAMES.ACTION_MOVE : preload("res://Data/World/Objects/Comps/Actions/action_move.gd"),
SCRIPT_ACTS_CONST.ACTION_NAMES.ACTION_SELECTABLE : preload("res://Data/World/Objects/Comps/Actions/action_selectable.gd")
}
## exports
## public vars
## private vars
## onready vars
# Obj_ for Node Refs
## built-in override methods
## public methods
static func initialize_actions(obj_caller:Node,actions:Array[Script]) -> void:
for action:Script in actions:
action.initialize_action(obj_caller)
## private methods
Data Const :
#meta-space-indent: 4
extends RefCounted
## enums
enum DATA_ENUMS{
#OBJDATA
OBJ_PATH,
OBJ_CURRENT_PATH_INDEX,
OBJ_PATH_GOAL,
OBJ_SELECTED,
OBJ_SELECTED_SPRITE,
MOVE_SPEED,
}
## consts
## exports
## public vars
## private vars
## onready vars
# Obj_ for Node Refs
## built-in override methods
## public methods
## private methods
Action Selectable:
#meta-space-indent: 4
extends RefCounted
## enums
## consts
const SCRIPT_DATA_MANAGER:= preload("res://Data/World/Objects/Comps/Data/main_data_manager.gd")
const SCRIPT_DATA_CONSTS:= preload("res://Data/World/Objects/Comps/Data/data_consts.gd")
const SPRITE_3D_CIRCLE_SELECTION: = preload("res://Data/Core/Templates/SelectionManager/SMComps/spite3d_selection_decal.tscn")
#ALIASES
const __DATA_CONSTS = SCRIPT_DATA_CONSTS.DATA_ENUMS
## exports
## public vars
## private vars
## onready vars
# Obj_ for Node Refs
## built-in override methods
# Called when the node enters the scene tree for the first time.
## public methods
static func initialize_action(caller:Node3D) -> void:
SCRIPT_DATA_MANAGER.set_data_vaule(caller,__DATA_CONSTS.OBJ_SELECTED,false)
var sprite_copy: =SPRITE_3D_CIRCLE_SELECTION.instantiate()
caller.add_child(sprite_copy)
sprite_copy.global_position = caller.global_position + Vector3(0,0.05,0)
SCRIPT_DATA_MANAGER.set_data_vaule(
caller,__DATA_CONSTS.OBJ_SELECTED_SPRITE,sprite_copy)
deselect_obj(caller)
static func select_obj(obj_caller:Node3D) -> void:_set_obj_selected_to(obj_caller,true)
static func deselect_obj(obj_caller:Node3D) -> void:_set_obj_selected_to(obj_caller,false)
static func toggle_select_obj(obj_caller:Node3D) -> void:
_set_obj_selected_to(obj_caller,
!SCRIPT_DATA_MANAGER.get_data_value(obj_caller,__DATA_CONSTS.OBJ_SELECTED)
)
## private methods
static func _set_obj_selected_to(obj:Node3D, set_selected_to:bool) -> void:
SCRIPT_DATA_MANAGER.set_data_vaule(obj, __DATA_CONSTS.OBJ_SELECTED,set_selected_to)
var object_selection_sprite:Sprite3D = (SCRIPT_DATA_MANAGER.get_data_value(obj,__DATA_CONSTS.OBJ_SELECTED_SPRITE) as Sprite3D)
object_selection_sprite.visible = set_selected_to
Base Unit:
#meta-space-indent: 4
extends MeshInstance3D
## enums
## consts
const SCRIPT_ACTS_MANAGER:= preload("res://Data/World/Objects/Comps/Actions/main_actions_manager.gd")
const SCRIPT_ACTS_CONSTS:= preload("res://Data/World/Objects/Comps/Actions/actions_conts.gd")
const SCRIPT_DATA_MANAGER:= preload("res://Data/World/Objects/Comps/Data/main_data_manager.gd")
const SCRIPT_DATA_CONSTS:= preload("res://Data/World/Objects/Comps/Data/data_consts.gd")
const OBJ_ACTIONS:Array[Script]= [
__ACTS_SCRIPTS[__ACTS_CONSTS.ACTION_MOVE],
__ACTS_SCRIPTS[__ACTS_CONSTS.ACTION_SELECTABLE],
]
#Aliases
const __ACTS_CONSTS:= SCRIPT_ACTS_CONSTS.ACTION_NAMES
const __ACTS_SCRIPTS:= SCRIPT_ACTS_MANAGER.ACTION_SCRIPT
const __DATA_ENUMS:= SCRIPT_DATA_CONSTS.DATA_ENUMS
## exports
## public vars
var obj_data:Dictionary ={}
## private vars
## onready vars
## built-in override methods
# Called when the node enters the scene tree for the first time.
func _ready() -> void:
_startup()
func _physics_process(delta: float) -> void:OBJ_ACTIONS[0].call_on_physics_tick(self,delta)
## public methods
func new_path(where_to:Vector3) -> void:__ACTS_SCRIPTS[__ACTS_CONSTS.ACTION_MOVE].path_new(self,where_to)
func select_obj()-> void:OBJ_ACTIONS[1].select_obj(self)
func deselect_obj()-> void:OBJ_ACTIONS[1].deselect_obj(self)
func toggle_select_obj()-> void:OBJ_ACTIONS[1].toggle_select_obj(self)
## private methods
func _startup() -> void:
SCRIPT_DATA_MANAGER.set_data_vaule(self,__DATA_ENUMS.MOVE_SPEED,12.0)
SCRIPT_ACTS_MANAGER.initialize_actions(self,OBJ_ACTIONS)
#obj_selection_aabb.show()
#obj_selection_aabb.mesh = BoxMesh.new()
#var selection_aabb:AABB = global_transform * mesh.get_aabb()
#var aabb_center: Vector3 = selection_aabb.position + selection_aabb.size * 0.5
#obj_selection_aabb.mesh.size = selection_aabb.size
#obj_selection_aabb.position = aabb_center
#obj_selection_aabb.queue_free()
Thank you for checking this out Thank you
