Can you change how the preview in the ColorPickerButton looks?

[introintroduction]

Godot Version

4.2.1

Question

Title, basically. I’m making the buttons in my project rounded, but I can’t figure out if there’s a way to make the Color Picker’s preview rounded as well. Is it possible to edit them?

[zdrmlpzdrmlp]

what type of node are these 3 colors rectangle?

[zdrmlpzdrmlp]

if the 3 colors are colorRect
then you use shader code like :

the code:

shader_type canvas_item;

uniform float radius_scale: hint_range(0.0, 1.0, 0.1) = 0.1;
uniform bool rounded_corner_top_left = true;
uniform bool rounded_corner_top_right = true;
uniform bool rounded_corner_bottom_left = true;
uniform bool rounded_corner_bottom_right = true;
uniform float width = 1.0;
uniform float height = 1.0;


void fragment() {
	vec4 image = texture(TEXTURE, UV);
	vec2 pos = vec2(UV.x*width, UV.y*height);
	float radius = min(width, height)*radius_scale/2.0;
	float dist;
	if (rounded_corner_top_left) {
		dist = length(pos - vec2(radius));
		if (dist > radius && pos.x < radius && pos.y < radius) {
			image.a = 0.0;
		}
	}
	if (rounded_corner_top_right) {
		dist = length(pos - vec2(width-radius, radius));
		if (dist > radius && pos.x > width-radius && pos.y < radius) {
			image.a = 0.0;
		}
	}
	if (rounded_corner_bottom_left) {
		dist = length(pos - vec2(radius, height-radius));
		if (dist > radius && pos.x < radius && pos.y > height-radius) {
			image.a = 0.0;
		}
	}
	if (rounded_corner_bottom_right) {
		dist = length(pos - vec2(width-radius, height-radius));
		if (dist > radius && pos.x > width-radius && pos.y > height-radius) {
			image.a = 0.0;
		}
	}
	vec4 color;
	color = mix(image.rgba, COLOR.rgba, image.a);
	COLOR.rgba = color.rgba;
}

modified version of Rounded corners - Godot Shaders so it can rounded rect the color rect

[introintroduction]

They are ColorPickerButtons! Thank you for the shader code though, if there isn’t a way to round the preview, I think I could use that to throw together my own version of the button.

[zdrmlpzdrmlp]

here i tested

modified code again:

shader_type canvas_item;

uniform float radius_scale: hint_range(0.0, 1.0, 0.1) = 0.1;
uniform bool rounded_corner_top_left = true;
uniform bool rounded_corner_top_right = true;
uniform bool rounded_corner_bottom_left = true;
uniform bool rounded_corner_bottom_right = true;
uniform float width = 1.0;
uniform float height = 1.0;
uniform vec4 back_color:source_color;


void fragment() {
	vec4 image = texture(TEXTURE, UV);
	vec2 pos = vec2(UV.x*width, UV.y*height);
	float radius = min(width, height)*radius_scale/2.0;
	float dist;
	if (rounded_corner_top_left) {
		dist = length(pos - vec2(radius));
		if (dist > radius && pos.x < radius && pos.y < radius) {
			image.a = 0.0;
		}
	}
	if (rounded_corner_top_right) {
		dist = length(pos - vec2(width-radius, radius));
		if (dist > radius && pos.x > width-radius && pos.y < radius) {
			image.a = 0.0;
		}
	}
	if (rounded_corner_bottom_left) {
		dist = length(pos - vec2(radius, height-radius));
		if (dist > radius && pos.x < radius && pos.y > height-radius) {
			image.a = 0.0;
		}
	}
	if (rounded_corner_bottom_right) {
		dist = length(pos - vec2(width-radius, height-radius));
		if (dist > radius && pos.x > width-radius && pos.y > height-radius) {
			image.a = 0.0;
		}
	}
	COLOR.rgba = mix(back_color, COLOR.rgba,image.a );
}
